SUS304 Stainless Steel Xenon Lamp Aging Test Chamber 8.5kw Power

1 Set
MOQ
US$2000-$30000
Price
SUS304 Stainless Steel Xenon Lamp Aging Test Chamber 8.5kw Power
Features Gallery Product Description Chat Now
Features
Specifications
Warranty: 1 Year
Customized Support: OEM, ODM, OBM, Software Reengineering
Place Of Origin: Guangdong, China
Model Number: CF8493
Power: 8.5kw
Temperature Range: RT+10℃~80℃
Humidity Range: 50%±5%
Application: Rubber, Paints, Coatings, Inks, Paper, Medicines, Food
Highlight:

Xenon Lamp Aging Test Chamber 8.5kw

,

SUS304 Xenon Lamp Aging Test Chamber

,

SUS304 xenon arc aging test chamber

Basic Infomation
Place of Origin: China
Brand Name: CHENGFENG
Certification: ISO,CE
Payment & Shipping Terms
Packaging Details: Wooden cases
Delivery Time: 10 Work Days
Payment Terms: T/T,Cash,L/C,Western Union,MoneyGram
Supply Ability: 5 units per month
Product Description

Xenon Arc Lamp Aging test Chamber SUS304 High-quality Stainless Steel



Performance indicators:

Temperature range: RT+10°C~80°C

Humidity Range: 50%±5%

Rainfall time: 1~9999 minutes, adjustable

Rainfall period: 1-240 minutes, adjustable interval (break).

Spectral wavelength: 300nm~400nm

Xenon lamp power: 8.5kw (lifespan: 2600 hours, water cooling)



Technical consultation telephone: 15322988080

Marketing Department Tel: 13266221899 TEL: 0769-33220970 FAX: 0769-33220970

Head office address: Changlian Industrial Building, Chang'an Xiabian, Dongguan City, Guangdong Province

Control Operating System: A PC can be used to control/operate the chamber system via IP connection

Lamp: 300mm long, 2 in total

Time Controller: Touch screen precision timing control

Accuracy range: set accuracy: temperature±0.1°C, humidity±0.5%R· H; Indication accuracy: temperature±0.1°C, humidity±0.5%R· H

Temperature and humidity sensor: platinum resistance Pt100Ω/mv

Humidification system: external isolated all-stainless steel shallow surface evaporative humidifier

Blackboard temperature: Bimetal blackboard thermometer 55°C~75°C

Water supply system: The humidified water supply is automatically controlled, and the xenon lamp cools the circulating water

Temperature controller: imported microcomputer temperature and humidity integrated controller

Humidity: 30%~65%RH when irradiated, up to 90%RH when dark

Radiation intensity: 0-60W/m²

Circulating system: temperature-resistant and low-noise air-conditioning motor, multi-leaf centrifugal wind wheel

Outer box material: high-grade sprayed color steel plate/SUS304 stainless steel matte line hairline treatment

Inner box material: SUS304 high-quality stainless steel light plate

Sample holder material: SUS304 high-quality stainless steel strip

Door frame insulation: high and low temperature aging resistant silicone rubber door seal

Standard configuration: 1 set of radiation-proof glass windows, 1 dynamic sample rack, 2 xenon lamps

Safety protection: leakage, short circuit, overtemperature, water shortage, motor overheating, overcurrent protection/controller power failure memory

Power supply voltage: AC380V±10% 50±0.5HZ three-phase five-wire system

Ambient temperature: ±5°C~+30°C ≤85%R· H

Water cooling system: 1 set, cooling system: 1 set

Xenon lamp power supply: 1 set

Number of test pieces: 5 pieces in a set

The thickness of the clamp is up to 120mm, and the thickness of the five clamps can be adjusted independently

Lab Space 1650mm x 1640mm x 2420mm (L*D*H)

Application industry:

Suitable for plastics, rubber, paints, coatings, inks, paper, medicines, food, cosmetics, textiles, auto parts, packaging materials, building materials, electrical products, etc.; It provides corresponding environmental simulation and accelerated tests for scientific research, product development and quality control, and provides an important test basis.

Compliance standards

This product conforms to GB/T16422.2, GB9344, GB/T1865-97, ASTM G 155-04a and other national standards.
