The entire test was carried out in a sealed laboratory with a volume of 4.32 cubic meters.
Combustion chamber:
1. Effective space: 2.4m (length) * 1m (width) * 1 .8m (height)
2. Dimensions: 2.4m (length) * 1m (width) * 2.5m (height)
3. Material:
Exterior: square steel frame structure, thickened 1.5mm steel plate electrostatic baking dark green paint;
Interior: Electrostatic baked black lacquer.
4. Observation window:
two left and right sliding windows; The viewing window is tempered glass;
The surrounding is edged with SUS304 stainless steel;
Size: 730mm (height) * 420mm (width).
5. Operation window: 4 in total
Inner space size: ф150mm;
Periphery: 3.0mm stainless steel edging;
Sealed with long-arm leather gloves with a length of 600mm;
Total peripheral dimensions: ф220mm.
6. Exhaust system:
two spiral exhaust fans;
The sealing push-pull plate is 2.0mm stainless steel;
Both sides are provided with sliding grooves;
One set of remote control operation device: a. two sets of steel rope type b. two sets of pulleys
7. Air inlet: 4 in total
Size: ф160mm;
The sealing push-pull plate is a 2.0mm stainless steel plate;
There are sliding grooves on both sides.
8. Bottom Fixing Stand:
Size: 2.4m (length) * 1m (width) * 0.7m (height);
Using 60mm*60mm*4mm angle iron, electrostatic baking dark green paint;
Foot pulleys: six, including 4 pulleys with locks.
9. Lighting equipment: adopt an anti-fog and smoke-proof round lamp
Control part
1. Burning indication 1pcs
2. Combustion setting: 0-99.99 seconds arbitrary setting
3. 1 stop ignition indicator
4. Stop ignition setting: 0-99.99 seconds arbitrary setting
5. Combustion count: 0-999999 times arbitrarily set
6. It has the functions of automatic combustion, combustion, stop ignition and counting
7. It has vertical/horizontal conversion function
8. It has automatic ignition function
9. It has manual/automatic conversion function
10. The ignition is a high-pressure ignition method
11. The test part is connected with the control, using aviation plug, and the contact is very close
