Digital Shore A and Shore D Durometer Hardness Tester ASTM D2240 ISO 868 with 500 Data Storage Thermal Printer for Rubber Plastic

Product Description

CF8518 Digital Shore A/D Durometer — Hardness Testing That Travels With You

Hardness is the most frequently measured parameter in rubber and plastic manufacturing—on the production floor, in the QC lab, and at incoming inspection. The CF8518 delivers ±1HA accuracy in a handheld package with 500-group data storage, built-in printing, and USB output. Fast, portable, traceable.

🔥 Why Thousands of Factories Choose the CF8518

✓ Dual Scale: Shore A + D — Measure soft rubber (Shore A: 0-100HA) and hard plastic (Shore D: 0-100HD) with ONE instrument. No switching tools.

✓ 500-Group Internal Memory — Every measurement is stored with date, time, and reading. Perfect for ISO 9001 traceability and customer audits.

✓ Instant On-Site Reports — Built-in thermal printer. Show your customer the hardness reading right there on the production floor.

✓ 20+ Hours Battery Life — Rechargeable Li-ion battery. Full shift on a single charge. No downtime.

✓ Statistics at Your Fingertips — Average, max, min, standard deviation calculated automatically. Know your process capability instantly.

✓ USB + RS-232 Output — Transfer data to Excel, SPC software, or LIMS. Eliminate manual transcription errors forever.

🎯 Common Hardness Testing Frustrations — Solved

"My operator reads the dial differently every time." → Digital display eliminates parallax error and subjective reading variation.
"I can't prove my hardness to the customer." → Printed report with timestamp provides irrefutable evidence.
"Recording hundreds of readings takes forever." → Press MEASURE → value auto-saved. 500 readings in one shift, no clipboard needed.
"Is this product really Shore A 65?" → Statistics mode shows average ± standard deviation. Detect process drift before it becomes a reject.

📊 Technical Specifications

Scale	Shore A (0-100HA) + Shore D (0-100HD) — dual scale
Accuracy	≤ ±1 HA / ±1 HD
Resolution	0.1 HA / 0.1 HD
Indenter — Shore A	35° truncated cone, ø1.25mm hardened steel
Indenter — Shore D	30° cone, R0.1mm tip, hardened steel
Data Storage	500 groups with timestamp
Output	USB, RS-232, built-in thermal printer
Standards	ASTM D2240, ISO 868, ISO 7619-1, DIN 53505, GB/T 531.1

🏭 Where the CF8518 Works Every Day

O-ring and seal production · Tire tread QC · Rubber hose inspection · Silicone kitchenware · Footwear sole testing · Automotive interior parts · Conveyor belt manufacturing · Plastic injection molding · TPE/TPU compounding · Incoming material inspection

📦 Package Contents

CF8518 durometer (Shore A + D) · Test stand with lever · Reference test blocks (HA & HD) · AC adapter · USB cable · Thermal printer with 5 paper rolls · Protective carrying case · English manual · Factory calibration certificate · 12-month warranty

💬 Quick Answers

Q: Can I use this to inspect incoming rubber sheets?
A: Absolutely. The handheld design is perfect for spot-checking rubber sheets, profiles, and molded parts on the loading dock or production line.

Q: Does it come with a test stand?
A: Yes! A lever-operated test stand is included for laboratory-grade consistent contact pressure per ASTM D2240.

Q: Can I export data to Excel?
A: Yes, connect via USB and use the included software to export all stored readings as CSV/Excel files.
