Precision Constant Temperature Oven Uses Circulating Air For Constant-Temperature Drying, Featuring A High Degree Of Intelligence

I. Product Overview and Application
This product uses circulating air for constant-temperature drying, featuring a high degree of intelligence. It does not require dedicated supervision. The temperature is intelligently and automatically adjusted according to the user's needs, achieving the drying effect in the shortest time. Its working temperature can be set from room temperature to the maximum. Within this range, the working temperature can be freely selected. Once selected, the temperature can be kept constant through the automatic control system inside the box. It is equipped with an electric blower to promote mechanical convection of hot air inside the room, making the indoor temperature more uniform.
Ii. Equipment Structure
This equipment is composed of imported high-quality warehouse panels. Between the working chamber and the box shell, high-efficiency insulation cotton is used as the insulation layer material, which has a good insulation effect and is safe and environmentally friendly. Opening the exhaust valve on the top of the box enables the cold and hot air in the working room to exchange through convection. The temperature control is automatically maintained at a constant temperature by a thermal expansion controller or a digital display instrument. All electrical operation equipment is installed in the control layer on the side of the box. There are side doors inside the control layer that can be removed for use when inspecting or repairing the circuits.

Iii. Performance Indicators
Note: The performance was measured after stabilizing for 2 hours without test load when the ambient temperature was +5 to +35℃. In addition, the temperature rise and fall times refer to the performance when the power supply voltage is normal and the ambient temperature is +25±5℃.
Temperature performance indicators
Temperature range: RT to +220 ℃
Temperature fluctuation: ≤±2℃
Temperature uniformity: ≤±5℃
Temperature rise time RT to 200 ℃ within 30 minutes (under no-load conditions)

2. Material and internal and external dimensions of the box body
The exterior decoration materials are high-quality imported cold-rolled steel plates with baked paint
The interior material is 304# steel plate
High-quality thermal insulation cotton as the thermal insulation material
Dimensions (meters) : Internal dimensions IH 1.2 ×IW 0.8 ×ID 0.8 M
The external dimensions are approximately IH 1.85 ×IW 1.35 ×ID 1.1 M
The content capacity is 800L
3. Equipment configuration
(1) Power supply: AC380V 50Hz
※ Allowable voltage variation range: ±5% of the rated value

※ (However, the operational range is ±10%)
(2) Maximum load capacity: 12KW
(3) Maximum current: 60A
(4) When placing the box, make sure the distance from the wall is more than 100mm.

Detailed technical parameters
Studio dimensions: 1800mm×1200mm×800mm
"Technology"
The parameter temperature range is RT+10℃ to +200℃
Fluctuation/uniformity: ±0.5℃/2±℃
The heating rate is nonlinear at 3℃/min
Box body
Material
The outer box is made of high-quality imported cold-rolled steel plate
The inner box is made of high-quality 304 steel plate
Insulation materials: Superfine insulation cotton/rigid polyurethane foam
The box door is sealed with double-layer high and low temperature resistant, anti-aging and anti-hardening refined silicone sealing strips
Hot and cold
Exchange
The system controller is an imported intelligent temperature control instrument
It has the function of P.I.D automatic calculation with high precision
The platinum resistance PT100Ω/MV of the temperature sensor
The circulating system is equipped with a temperature-resistant and low-noise motor, featuring single circulation, extended shaft, and stainless steel multi-blade centrifugal fan blades
The heating method is isolated stainless steel heating tube
Timing function: 0.1-99.99 (S, M, H)
Security device power leakage protection, over-temperature protection (with sound signal prompt), quick fuse
The standard configuration includes two layer disks
The power supply voltage is AC 380V·50HZ
Operating ambient temperature: 15℃ to +30℃, ≤ 85% R.H

Main configuration
Name, quantity, Specification, material
The outer box material is one batch of high-quality cold-rolled steel plates with electrostatic powder coating
The inner box material is one batch of SUS304 stainless steel plates
One batch of high-density rigid polyurethane foam insulation material
One batch of double-layer high and low temperature resistant, anti-aging and hardening refined silicone sealing strips for the box door seal
One intelligent P.I.D controller
One set of temperature sensor with PT100Ω/MV platinum resistance
One motor with high temperature resistance and low noise
One multi-blade centrifugal fan with single circulation and an extended shaft made of stainless steel
One isolated stainless steel heating tube

Iv. Box Body and Equipment
1. Equipment items
Original imported Omron temperature control (with an over-temperature meter) key controller
Running time: 0 to 9999 minutes
It is controlled by a high-power relay heating component
The temperature controller adopts an imported P+I+D method to control temperature heating
The overall control system of the machine is designed with electromagnetic contactors
The digital display high-precision timer allows for the setting of the constant-temperature baking time
Multi-color indicator lights indicate the usage status of the oven
It is equipped with an over-temperature or baking completion indication function, and has an indicator light alarm system
It is equipped with an over-temperature preventer. Once an abnormal over-temperature occurs, it will automatically protect and stop heating
There is no fuse switch protection. The power supply will be automatically cut off when there is abnormal overload
2. Heating system
The left and right sides of the box are equipped with nickel-chromium heating tubes from Taiwan
Blower: Centrifugal multi-blade fan
Air supply mode: One 2HP long-shaft motor is used for horizontal and lateral air supply to ensure uniform temperature.
Heater: Anti-vibration and anti-collision finned heater (nickel-chromium alloy)
Temperature sensor: PT100 type thermal resistance (dry ball)
3. Ventilation system
There is an 80MM ventilation opening on each side, which has a remarkable ventilation effect.

V. Safety Devices
Temperature overrise preventer (protecting the test subject and the test chamber)
High-speed circuit protector (for protecting the heating circuit)
<s:1> Motor (blower) overload thermal relay (protecting blower overload)
Protect the circuit breaker of the motor

Vi. Ancillary Functions
The timing function (automatic start and automatic stop)
The alarm display function
