Home /Products/Rubber Testing Equipment/ISO 7619 Digital Shore A D Durometer Hardness Tester for Rubber Plastic Material Testing CF8383

ISO 7619 Digital Shore A D Durometer Hardness Tester for Rubber Plastic Material Testing CF8383

1 Set
MOQ
USD 500-1500 / Set
Price
ISO 7619 Digital Shore A D Durometer Hardness Tester for Rubber Plastic Material Testing CF8383
Features Gallery Product Description Chat Now
Features
Specifications
Scale Type: Shore A / Shore D
Measurement Range: 0-100 HA / 0-100 HD
Resolution: 0.1 Unit
Accuracy: ±1 Unit
Presser Foot Diameter: 18mm ±0.5mm
Display: LCD With Backlight
Data Output: USB Interface
Power Supply: Rechargeable Li-ion Battery
Operating Temperature: 0-50°C
Highlight:

ISO 7619 Shore A hardness tester

,

digital durometer for rubber testing

,

plastic material hardness tester
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: CHENGFENG
Certification: ISO 9001:2015, CE
Model Number: CF8383
Payment & Shipping Terms
Packaging Details: Standard export carton with shock-proof foam insert
Delivery Time: 5-10 working days
Payment Terms: T/T,L/C,Western Union,PayPal
Supply Ability: 200 Sets per Month
Product Description

ISO 7619 Digital Shore Durometer CF8383

The CF8383 Digital Shore Durometer provides precise hardness measurement of rubber, elastomers, plastics, and thermoplastic materials according to ISO 7619, ASTM D2240, and DIN 53505 standards. Available in Shore A and D configurations with a large LCD display and USB data output for quality control and R&D applications.

Key Features

  • ISO 7619 & ASTM D2240 Compliant: Full compliance with international Shore hardness measurement standards.
  • Dual Scale Display: Simultaneous Shore A and D readings with 0.1 unit resolution for high-precision measurement.
  • Digital LCD with Backlight: Clear reading display in all lighting conditions with peak hold and statistical functions.
  • USB Data Output: Real-time data transfer to PC via USB with included statistical analysis software for SPC applications.

Technical Specifications

ParameterSpecification
Scale TypeShore A / Shore D
Measurement Range0-100 HA / 0-100 HD
Resolution0.1 unit
Accuracy±1 unit
Indenter TypeTapered cone (A), Sharp cone (D)
Spring Force (Shore A)550+75H (mN) at 0-100 HA
Spring Force (Shore D)44450H (mN) at 0-100 HD
Presser Foot Diameter18mm ±0.5mm
DisplayLCD with backlight
Data OutputUSB interface
Power SupplyRechargeable Li-ion battery
Test Stand CompatibilityOptional CF8383-ST motorized stand
Operating Temperature0-50°C
Net WeightApprox. 0.5kg

Compliance Standards

ISO 7619-1, ISO 48-4, ASTM D2240, DIN 53505, GB/T 531.1

Standard Accessories

  • Digital Shore durometer unit (A or D type)
  • Reference test block
  • USB cable with software CD
  • Carrying case
  • Operation manual and calibration certificate

Quality Assurance

12-month warranty with lifetime remote technical support.
