ISO 6502 Moving Die Rheometer Rubber Vulcanization Testing Machine Rotorless Cure Meter for Laboratory CF8388

ISO 6502 Moving Die Rheometer (MDR) CF8388

The CF8388 Moving Die Rheometer (MDR) is an advanced rotorless cure meter that measures the vulcanization characteristics of rubber compounds according to ISO 6502 and ASTM D5289. It provides complete cure profiles including ML, MH, ts1, ts2, t10, t50, t90, cure rate index, and tan delta, making it essential for rubber compound development, quality control, and production process optimization.

Key Features

• ISO 6502 & ASTM D5289 Compliant: Rotorless sealed cavity design with biconical die geometry for accurate and reproducible vulcanization curves.
• Complete Cure Profile: Automatic calculation of ML, MH, ts1, ts2, t10, t50, t90, CRI, S'@ML, S'@MH, and tan delta with real-time torque and temperature curves.
• High-Frequency Oscillation: 1.67Hz (100cpm) oscillation frequency with ±0.5° arc amplitude for standard testing, with optional 0.5° to ±3° variable amplitude.
• Fast Temperature Recovery: Closed-loop die heating with PID control achieves temperature recovery within 30 seconds after specimen loading for maximum testing productivity.

Technical Specifications

Compliance Standards

ISO 6502, ASTM D5289, GB/T 16584

Standard Accessories

• MDR main unit with sealed dies
• Specimen cutting die and template
• Nylon isolation film (200 sheets)
• Built-in thermal printer
• USB cable with analysis software
• Operation manual and calibration certificate

Quality Assurance

12-month warranty with on-site installation and training available.
