DIN 53516 ISO 4649 Digital Rubber Abrasion Resistance Tester Rotary Drum Abrader with Automatic PLC Control 0.001g Balance

Product Description

CF8568 DIN 53516 Rubber Abrasion Resistance Tester — Because Your Product's Wear Life Defines Your Brand

Every kilometer your customer's tire rolls, every step they take in your shoes, every cycle your conveyor belt runs—abrasion is eating away at your product. The CF8568 DIN Abrasion Tester quantifies that wear precisely, so you can formulate rubber compounds that outlast the competition. DIN 53516 · ISO 4649 · ASTM D5963 · GB/T 9867 compliant.

🔥 What Makes the CF8568 the Top Choice

✓ All-in-One Testing — Built-in 0.001g density balance. Measure mass loss, calculate density, get final volume loss—all in one machine. No separate balance needed.

✓ Automatic Test Cycle — PLC-controlled 40m abrasion distance (84 drum revolutions). Auto-stop. Zero operator counting errors.

✓ Dual Load: 5N & 10N — Standard 10N for most rubbers, 5N for softer or thinner materials. One-touch switching.

✓ Lateral Sample Traverse — Sample moves sideways during rotation. Always wears against fresh abrasive surface. No track grooving artifacts.

✓ Reference Compound Included — Calibrate your abrasive sheet condition before every test batch. Results you can defend to any customer.

✓ Touch Screen + Data Export — View results, export via USB, print reports. Modern interface—no cryptic buttons.

🎯 Critical QA Problems This Machine Prevents

"Our customer says our rubber wears too fast." → Now you have a DIN volume loss number to benchmark and improve. Data beats opinions.
"Different batches wear differently." → Incoming compound testing catches abrasive filler dispersion problems before they become warranty claims.
"We don't know how we compare to competitors." → Test competitor samples. The DIN abrasion index is the universal rubber wear language.
"Our lab technician gets inconsistent results." → Automatic cycle control eliminates the biggest source of variation: the human operator.

📊 Key Performance Data

Test Standards	DIN 53516, ISO 4649, ASTM D5963, GB/T 9867
Drum	ø150 ± 0.2mm * 460mm, 40 ± 1 rpm
Abrasion Distance	40m standard (adjustable via touch screen)
Sample Load	5N or 10N ± 0.2N, selectable
Abrasive Sheet	60-grit Al₂O₃, 400mm * 474mm (2 sheets included)
Balance	Built-in electronic, 0.001g resolution, 200g capacity
Result Output	Volume loss (mm³), Density (g/cm³), Abrasion Resistance Index (ARI)

🏭 Industries That Rely on DIN Abrasion Data

Tire tread compound development · Shoe sole manufacturing · Rubber conveyor belt production · Floor covering and sports surface testing · Rubber seal and gasket wear evaluation · Hose cover compound QC · Printing roller rubber · Rubber compound R&D laboratories

📦 Complete Testing Kit

CF8568 main unit · Sample cutting die (ø16mm) · Density balance (built-in) · Abrasive sheets (*2) · DIN reference compound No.1 · Calibration weight · Sample holder and accessories · Touch screen controller · Dust extraction port · English manual · Calibration certificate · 12-month warranty

💬 DIN Abrasion — What Buyers Ask

Q: DIN vs Akron — which is better?
A: DIN 53516 (rotary drum) is the global standard for general rubber wear. Akron is used primarily for tire compounds. The CF8568 performs the DIN method—which is the broader market standard.

Q: How often do I replace the abrasive sheet?
A: After each test. Each sheet provides approximately 10-15 test tracks. The machine lateral movement ensures fresh track usage.

Q: How long does one test take?
A: Approximately 2 minutes of abrasion time + sample weighing. A complete test with 3 samples takes ~15 minutes.
