ASTM D471 ISO 1817 Rubber Oil Fuel Solvent Immersion Resistance Tester 12-Station PID Temperature Control to 300°C

Product Description

CF8575 ASTM D471 Oil & Solvent Immersion Tester — Know Exactly How Your Rubber Survives in Harsh Fluids

When your rubber seal sits in hot engine oil at 150°C for 1,000 hours, will it swell? Crack? Dissolve? The CF8575 gives you that answer before your customer ever finds out. 12 independent stations · 300°C PID control · ASTM D471 / ISO 1817 / GB/T 1690 compliant. The data that protects your reputation.

🔥 Why the CF8575 Is Your Competitive Advantage

✓ 12 Independent Test Stations — Run different fluids at different temperatures simultaneously. 12 tests in parallel = 12x the throughput.

✓ Sealed 304 SS Containers — Each station has its own sealed stainless steel vessel. No fluid cross-contamination. No evaporation during long tests.

✓ ±0.5°C PID Accuracy — Precise temperature control to 300°C. Critical when testing near fluid boiling points or simulating engine conditions.

✓ 0-9999 Hour Timer — Set your immersion duration. Machine auto-stops. Run 70-hour, 168-hour, or 1000-hour tests unattended.

✓ Magnetic Stirring Option — Uniform fluid temperature and concentration. No hot spots skewing your results.

✓ Full Safety Suite — Over-temperature cutoff, fluid level sensor, fume extraction port, and emergency stop. Sleep well during overnight tests.

🎯 Expensive Problems the CF8575 Prevents

"Our O-ring swelled and the hydraulic system leaked." → Pre-qualify seal materials against your actual operating fluid at operating temperature. No surprises.
"The fuel hose delaminated after 6 months." → ASTM D471 immersion testing simulates years of service. Find incompatible material combinations before production.
"Our customer switched to bio-diesel and our gaskets failed." → Test new fuel formulations proactively. Be the supplier who says "we've already qualified for that."
"We don't know which NBR grade is right for this oil." → Test multiple compounds side by side in the same fluid. Data-driven material selection.

📊 Performance Specifications

Temperature Range	Ambient +5°C ~ 300°C, ±0.5°C accuracy
Test Stations	12 independent (expandable to 24)
Container	304 stainless steel, 500mL, sealed with O-ring lid
Timer	1 min ~ 9999 hours, independent per station
Test Fluids	ASTM #1/#2/#3/#5 oils, Fuel A/B/C/D, IRM 901/902/903, water, chemicals
Measured Properties	ΔMass (%), ΔVolume (%), ΔHardness (Shore A/IRHD), ΔTensile, extractables
Standards	ASTM D471, ISO 1817, GB/T 1690

🏭 Products That Must Pass This Test

Automotive engine seals and gaskets · Fuel system O-rings and hoses · Hydraulic cylinder seals · Chemical plant gaskets · Oil field equipment rubber · Aerospace fuel bladder materials · Refrigeration compressor seals · Medical plunger stoppers

📦 Equipment Package

CF8575 main unit with 12 stainless steel containers · Magnetic stirring modules · Temperature controller with touch screen · Sample suspension racks · Spare O-ring seals for containers · English operation manual · Factory calibration certificate · 12-month warranty

💬 Buyer FAQs

Q: What oil types can I test with?
A: ALL ASTM and IRM reference oils, plus your customer's actual service oil, transmission fluid, brake fluid, coolant, and any liquid chemical. If it's a liquid below 300°C, the CF8575 can test rubber in it.

Q: How long does a typical test run?
A: Per ASTM D471: 70 hours at specified temperature is standard. But you can program any duration from 1 minute to 9999 hours (over 1 year).

Q: Can I test at multiple temperatures simultaneously?
A: Yes, each station has independent temperature control. Test fluid A at 100°C and fluid B at 150°C in the same run.

Q: What property changes do I measure after immersion?
A: Weight change · Volume swell/shrinkage · Hardness change (need separate durometer) · Tensile property change (need separate tensile tester). The CF8575 performs the immersion; you measure properties after.
