FTIR Fourier Transform Infrared Spectrometer with Diamond ATR for Rubber Polymer Material Identification and Composition Analysis

FTIR Fourier Transform Infrared Spectrometer with Diamond ATR for Rubber Polymer Material Identification and Composition Analysis
Features Gallery Product Description Chat Now
Features
Specifications
Highlight:

FTIR spectrometer with diamond ATR

,

Rubber polymer material identification spectrometer

,

Fourier transform infrared composition analyzer
Basic Infomation
Payment & Shipping Terms
Product Description

CF8620 FTIR Spectrometer — The Ultimate Rubber Detective in Your Lab

In 30 seconds, identify any rubber or polymer. The CF8620 FTIR with diamond ATR is your forensic tool for competitor product analysis, incoming material verification, contamination investigation, and formulation reverse engineering. Simply press the rubber sample against the diamond crystal—no preparation, no chemicals, no waiting.

🔥 The CF8620 — Your Competitive Intelligence Weapon

✓ Diamond ATR — Universal Sampling — Press ANY solid or powder directly on the crystal. Hard rubber, soft silicone, sticky adhesives, brittle plastics—all work. No KBr pellets. No solvents. No prep.
✓ 10,000+ Rubber & Polymer Library — Built-in spectral database covering NR, SBR, NBR, EPDM, CR, IIR, BR, silicone, FKM, PU, and more. One click auto-match.
✓ 50,000:1 Signal-to-Noise — Detect trace additives (antioxidants, plasticizers, processing aids) that cheaper FTIRs miss. Full formulation insight.
✓ 0.5 cm⁻¹ Resolution Option — Resolve closely spaced peaks for definitive polymer identification. No ambiguous "it might be SBR or maybe BR" results.
✓ Quantitative Analysis Tools — Measure filler content (silica, CaCO₃, clay), blend ratios (NR/SBR, NBR/PVC), and plasticizer levels. Go beyond identification.
✓ Purge-Ready Sealed Optics — Humidity-protected interferometer. No desiccant panic. Stable baselines even in tropical labs.

🎯 Business Problems the CF8620 Answers in Minutes

  • "What polymer is our competitor using?" → Press competitor product on diamond. 30 seconds. Answer on screen. Competitive advantage delivered.
  • "Is this really the EPDM we ordered?" → Incoming material check takes 1 minute. Reject contaminated shipments before they enter your production.
  • "Why did this rubber part fail?" → Compare failed part spectrum to reference. See if material changed, degraded, or was contaminated.
  • "Can we make this product cheaper without losing performance?" → Analyze competitor formulations. Identify optimization opportunities. Informed cost reduction.

📊 Technical Specifications

Spectral Range7800 ~ 350 cm⁻¹ (covers ALL functional groups)
Resolution0.5 / 1 / 2 / 4 cm⁻¹ (selectable for speed vs detail)
S/N Ratio≥ 50,000:1 (1 min scan, 4 cm⁻¹, 2100 cm⁻¹)
ATR CrystalMono-crystal diamond — wear-resistant, universal pH range
DetectorTemperature-stabilized DTGS — no liquid nitrogen needed
Polymer Library10,000+ spectra, searchable by name, peak, or full spectrum
Analysis FunctionsLibrary search · Spectrum subtraction · Peak ratio · Quantitative calibration · Report generation

🏭 Business Applications

Rubber compound R&D · Competitor product analysis · Incoming raw material QC · Contamination failure analysis · Polymer grade verification · Tire compound development · Seal and gasket material ID · Recycling material classification · University & contract research labs

📦 Complete Analysis System

CF8620 FTIR main unit · Diamond ATR accessory · Transmission sample holder · PC with pre-installed software and polymer library · Printer · Calibration standard (polystyrene film) · Desiccant · English manual · Factory calibration certificate · 12-month warranty

💬 FTIR — What Buyers Want to Know

Q: How quickly can I identify an unknown rubber?
A: Place sample on ATR → Click "Collect" → Click "Search Library" → result in < 60 seconds. Even faster with the one-click ID macro.

Q: Can it identify carbon black-filled rubber?
A: Carbon black absorbs IR strongly, but the included spectral subtraction tool removes carbon black background for clearer polymer identification.

Q: Do I need liquid nitrogen?
A: No. The CF8620 uses a room-temperature DTGS detector. No cryogen costs, no LN2 logistics. Just plug in and measure.

Q: What file formats can I export?
A: SPC (universal spectroscopy format), CSV (Excel), TXT, and PDF reports. Compatible with major spectral databases.
