GB/T9978 Fire Resistant Vertical Furnace For Building Components Fire Resistance

1 Set
MOQ
US$2000-$30000
Price
GB/T9978 Fire Resistant Vertical Furnace For Building Components Fire Resistance
Features Gallery Product Description Chat Now
Features
Specifications
Internal Dimensions: 4.5m (l) *3.5m (d) *4.25m (h)
Furnace Structure: Steel Structure Framec
Inside The Furnace Wall: High Temperature Resistant Insulation Material
Furnace Wall Density: Greater Than 1000kgpm ³
Outer Side: Wrapped In Color Steel
Furnace Lining Material Thickness: 65mm
Furnace Temperature: The Test Temperature Is As High As 1250 ℃.
Highlight:

GB/T9978 fire resistant vertical furnace

,

building components fire resistance tester

,

vertical furnace for fire testing
Basic Infomation
Place of Origin: China
Brand Name: CHENGFENG
Certification: ISO,CE
Model Number: CF8364
Payment & Shipping Terms
Packaging Details: Wooden cases
Delivery Time: 10 Work Days
Payment Terms: T/T,Cash,L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 5 units per month
Product Description

Scope of application: It is applicable to determining the fire resistance characteristics of horizontal building components such as walls, beams, columns, floor slabs and ceilings under standard fire exposure conditions. Comply with the test requirements of standards such as GB/T9978.1-2008, ISO834-1:1999, GB/T9978.5-2008, ISO834-5:2000, GB/T9978.6-2008, and ISO834-6:2000.



Performance features: It adopts high-precision multi-position acquisition cards to collect data from various aspects such as temperature, pressure and flow rate of each channel. Through microcomputer analysis, processing and control, it generates real-time reproduction of the real information during combustion. The combustion characteristics are determined by microcomputer analysis. The whole machine is made of high-quality components to ensure the high-quality and high-speed operation of the system, which is advanced.

Technical parameters 1. Instrument composition: Refractory test furnace, gas flow measurement system, temperature measurement system and pressure measurement and control system. 2. Refractory test furnace: It is a vertical test furnace with internal dimensions of 4.5m (length) ×3.5m (depth) ×4.25m (height). 3. Furnace structure: A steel structure frame is adopted. The furnace wall is built with refractory bricks in the middle of the steel structure frame. The inner side of the furnace wall is made of high-temperature resistant insulation material with a density greater than 1000kgpm³. The outer side is wrapped with color steel, and the thickness of the inner lining material of the furnace is 65mm. The temperature test temperature inside the furnace can reach up to 1250℃.
