RH‑10K Plastic Tensile Testing Machine

Product Features

It is mainly used for testing conventional mechanical‑performance indicators of various rubbers, plastics, metals, non‑metals and composite materials. Adopting imported technology with full‑digital amplification, data acquisition and closed‑loop control, it delivers stable display, high accuracy and easy operation.

1. Overview

The RH‑10K plastic tensile testing machine is designed to test conventional mechanical‑performance indicators for various rubbers, plastics, metals, non‑metals and composite materials. Built with imported technology, full‑digital amplification, data acquisition and closed‑loop control, it features stable display, high measuring accuracy and user‑friendly operation. The main unit is equipped with well‑known brand motor and speed‑regulation system, precision reducer and high‑precision lead screw, ensuring smooth transmission, low noise, high speed accuracy, wide speed‑adjusting range and long service life. Real‑time LCD display supports compression, bending, peeling, tensile, tearing, elongation and other mechanical tests. It boasts elegant appearance, simple operation and convenient use. Functions including limit protection, automatic overload protection and automatic stop upon specimen fracture are available.

2. Main Technical Specifications

1. Test force measuring range: 10 kN
2. Test force ranges: 4 ranges
3. Test force measuring accuracy: 0.01 %
4. Speed range: 5～500 mm/min (adjustable)
5. Tensile stroke: 0～800 mm (excluding grippers)
6. Compression space: 0～800 mm
7. Power supply: 220 V, 50 Hz
8. Overall dimension: 720×450×1600 mm
9. Weight: 220 kg

3. Function Description

1. Automatic calibration: The system can automatically calibrate the indication accuracy.
2. Manual range shift: Manually switch to proper range according to test‑force magnitude to guarantee accurate measured data.
3. Real‑time display: The LCD screen shows test force and peak value in real time throughout the test process.
4. Fracture detection: The moving cross‑beam stops automatically once the specimen breaks.
5. Limit protection: Dual‑level limit protection including mechanical limit and program‑controlled limit.
6. Multi‑purpose machine: Multi‑function application achievable by fitting different sensors.

A micro thermal printer is available as an option. Printable items: date, batch number, test count, force value, fracture value, average value, sampling point value and capacity. This function is available upon customer’s request.
