High Precision Salt Spray Corrosion Tester GB/T2423.17-2008 GB/T 2423.18-2000GB

 Product usage:

Hardware special salt spray corrosion testing machine is a kind of artificial simulation of salt spray environment test, it has
significant advantages compared with the exposure test under atmospheric conditions: the corrosion environment can be controlled, and the environment reproducibility is good; The test time is significantly shortened; It saves a lot of manpower, financial and
material resources. Its development and promotion are both fast. It has developed from the initial simple neutral salt spray test
to various forms such as acetate spray test, salt-accelerated acetate spray test and alternating salt spray test. The salt spray
test chamber uses a saline-containing solution or acidic saline solution to accelerate the corrosion of a material or product
under a certain temperature and relative humidity environment, and reproduces the degree of damage suffered by the material or
product within a certain time range. The equipment can be used to assess the ability of materials and their protective layers to
resist salt spray corrosion, as well as the comparison of the process quality of similar protective layers, and can also be used
to assess the ability of certain products to resist salt spray corrosion.

Salt spray test reference standard:

GB/T2423.17-2008,GB/T 2423.18-2000GB/T10125-1997GB/T10587-2006
GB10593.2-1990,GB/T1765-1979,GB/T1771-2007,
GB/T12967.3-2008,GB/T5170.8-2008
and equivalent IEC, MIL, DIN, ASTM and other related standards

Product material:

a: Box material: ★ The inner and outer boxes of this machine are made of A-grade gray PVC (thickness 5mm) with high temperature
resistance, high humidity and high corrosion resistance imported from Germany, and are welded by using advanced ring belt
production three-dimensional reinforcement technology, with strong structure, never deformed, gorgeous and generous, suitable for
various test specifications such as salt water spray and copper acetate.
b: Test drug refill bottle: ★ Hidden integrated test drug refill bottle, easy to clean and operate.
c: Pressure saturation barrel: ★ Using A-grade gray PVC material imported from Germany, exquisite tank structure design, high
temperature resistance, high humidity, high pressure, high corrosion, non-rusty, relieving the confusion of long-term use of
stainless steel rust. There has been a cross-generational progress in design.
d: Laboratory shelf: ★ The A-grade gray PVC material imported from Germany is exquisitely designed into a "V" shaped strip, and
the carbon fiber straight diameter is 10mm "O" shaped strip to ensure that the product under test can be adjusted at will from
15°-30° angle. The test sample holder adopts the plane indexing type, the angle can be adjusted arbitrarily, the fog falls evenly
on all sides, the fog is completely consistent, the test results are accurate, and the number of test samples is large.
e: The upper cover of the laboratory: ★ the 8mm thick and high toughness transparent acrylic (imported) plate is used, and the
100-degree ridge transparent upper cover is designed by the physical bending method. The mist dew remaining on the upper cover
slides down the cover wall to the sealing groove. to prevent dripping onto the product being tested.
F: ★ With self-detection, self-detection and other corresponding advanced functions, it is an excellent choice for you to get
twice the result with half the effort.
G: ★ Full digital circuit design, accurate temperature control, using high-quality imported electrical materials, reasonable
wiring design, long service life, complete testing functions.
h: ★ With automatic/manual water filling function, the water level can be automatically replenished when the water level is
insufficient without interrupting the test.
i: ★ It has the function of remembering the power failure time, so that the test work of the remaining time can be completed
according to the original time after the call, with double over-temperature protection, and the water level is insufficient to
warn to ensure the safety of use.
J: ★ The mist sealing tank uses an environmentally friendly water sealing method to prevent mist leakage.
K: ★ The spray tower adopts a conical disperser, which has the functions of guiding the fog, adjusting the fog volume and evenly
falling the fog.
L: ★ The instrument adopts ergonomic design, beautiful appearance, easy operation, and at the end, the buzzer beeps to alarm.

Technical basis:

According to JIS, ASTM, CNS, GB standard parameter operation setting.
a Saline spray test; NSS ,ACSS.
Laboratory: 35°C±1°C.
Pressure air barrel: 47°C±1°C.
B Corrosion resistance test: CASS.
Laboratory: 50°C±1°C.
Pressure Air Barrel: 63°C±1°C.
c: Air supply system: ★ The air pressure is 1Kg/cm2 and adjusted in two stages. The first section is roughly adjusted by 2Kg/cm2,
and an imported air filter is adopted, with a drainage function. The second stage is a precision adjustment of 1Kg/cm2, 1/4
pressure gauge, the display is precise and accurate.
