Cable Compression Resistance Testing Machine Complies With The Requirements Of The GB12972 Standard.

1 Set
MOQ
US$2000-$30000
Price
Cable Compression Resistance Testing Machine Complies With The Requirements Of The GB12972 Standard.
Features Gallery Product Description Chat Now
Features
Specifications
Maximum Measured Load:: 50KN(5T)
Maximum Stroke:: 800MM
Test Speed:: Continuously Adjustable From 50 To 500 Mm /MIN
Test Voltage Regulation:: Adjustable From 0 To 1.5KV
Power Supply:: 220V,50Hz, 1500W
Load Resolution:: 0.01KG
Highlight:

Cable compression resistance tester

,

GB12972 standard testing machine

,

Cable testing equipment with warranty
Basic Infomation
Place of Origin: China
Brand Name: CHENGFENG
Certification: ISO,CE
Model Number: CF8466
Payment & Shipping Terms
Packaging Details: Wooden cases
Delivery Time: 10 Work Days
Payment Terms: T/T, Cash.L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 5 units per month
Product Description

It is applicable to the compression resistance performance of mining cables below UC-0.66KVT and UCP-1.14KV. Complies with the requirements of the GB12972 standard.

Maximum measured load: 50KN(5T).

Load resolution: 0.01KG.

Maximum stroke: 800MM.

Test speed: Continuously adjustable from 50 to 500 mm /MIN.

Test voltage regulation: Adjustable from 0 to 1.5KV.

Automatic stop function: In case of short circuit or open circuit of the sample, the power will be cut off and the action will be resumed. The moving crossbeam will automatically stop (or automatically return to the initial position).

It features two-level limit protection, namely program-controlled and mechanical.

When the load exceeds the rated value by 3 to 5%, the machine will automatically shut down.

Net weight of the equipment: 130Kg.

Power supply: 220V,50Hz, 1500W.
