PID testing system

PID testing system





Meet the standards:
IEC61215-2 MQT21
IEC62804









Product Introduction

The PID power supply has multiple channel outputs, which can provide multiple components for simultaneous testing. The voltage can be continuously adjusted, and the voltage parameters can be displayed in real time.





1. The power supplies are independent of each other and can output different polarities and voltage values at the same time.
2. PID monitoring communication, and according to the customer's customized time requirements, the system outputs high voltage to test the tested sample on its own. The system can monitor the temperature and humidity inside the environmental test chamber according to the latest standard requirements (communicate online with high-temperature and high humidity equipment)
When the environmental testing chamber (equipped with Baishiqi environmental chamber) malfunctions, the PID power supply will automatically receive the fault information from the environmental testing chamber. The software will force the power system output to "0" to avoid damage to the test samples and ensure the safety of the equipment due to the incompatibility of the dual systems.
4. The power supply has a leakage current alarm function, and the alarm range can be set.





Main equipment parameters:

Input voltage: AC 220V ± 10%

Output voltage: DC-2000V to+2000V (continuously adjustable) can be upgraded to DC-2500V to+2500V

Voltage accuracy: 1000V 1500V 2000V continuous output, voltage fluctuation within 500 hours ≤ 0.5%



Maximum rated current: 250uA/channel

Current accuracy: 1uA+1% F · S

Test channel: Customer defined
