Firestop test furnace

Firestop test furnace

Technical parameters
1. Implementation standard: New version of GB 23864-2023 "Fireproof Sealing Materials".
2. Main purpose of the equipment: It can conduct fire resistance tests on all vertical sealing materials except for gap sealing materials.
3. Equipment highlights: - Small footprint, easy installation; -Equipped with sealed furnace walls and set up test openings; -Meet the fiber temperature rise curve and power temperature rise curve requirements in the new standard.
4. Equipment dimensions: - Standard version: height 1.6 meters, width 1.6 meters, depth 1 meter - High spec version: height 1.6 meters, width 2.6 meters, depth 1.6 meters
5. Furnace structure: The main structure is a steel structure, and the lining material is high alumina refractory fiber with a fiber thickness of 300mm.
6. Fuel: liquefied petroleum gas or natural gas.
7. Combustion control mode: single burner, separate PLC automatic control.
8. Furnace pressure control method: PLC automatic control.
9. The maximum temperature inside the experimental device furnace is 1250 ℃, and at this temperature, the maximum temperature rise on the outer wall of the furnace is 30 ℃.
