Fire penetration seal fire resistance test furnace

Fire penetration seal fire resistance test furnace

Technical parameters
1. Implementation standard: New version of GB 23864-2023 "Fireproof Sealing Materials".
2. Main purpose of the equipment: It can conduct fire resistance tests on all vertical sealing materials except for gap sealing materials.
3. Equipment highlights: - Small footprint, easy installation; -Equipped with sealed furnace walls and set up test openings; -Meet the fiber temperature rise curve and power temperature rise curve requirements in the new standard.
4. Equipment dimensions: - Standard version: height 1.6 meters, width 1.6 meters, depth 1 meter - High spec version: height 1.6 meters, width 2.6 meters, depth 1.6 meters
5. Furnace structure: The main structure is a steel structure, and the lining material is high alumina refractory fiber with a fiber thickness of 300mm.
6. Fuel: liquefied petroleum gas or natural gas.
7. Combustion control mode: single burner, separate PLC automatic control.
8. Furnace pressure control method: PLC automatic control.
9. The maximum temperature inside the experimental device furnace is 1250 ℃, and at this temperature, the maximum temperature rise on the outer wall of the furnace is 30 ℃.

The device contains content
1. Furnace body
2. Refractory materials
3. Combustion system
4. Electrical control system
5. Liquefied gas pressure reduction system (not available when the gas source is natural gas)
6. Test frame
