TTI-350 Tracking Index Tester Temperature Recording for Epoxy Resin Insulation Material

1 Set
MOQ
USD 7300-10100 / Set
Price
TTI-350 Tracking Index Tester Temperature Recording for Epoxy Resin Insulation Material
Features Gallery Product Description Chat Now
Features
Specifications
Test Standard: IEC 60112, GB/T 4207
Test Voltage: 100V-600V AC Adjustable
Drop Volume: 20 Mm3 (+3/-0)
Drop Height: 30-40mm
Drop Rate: 1-60 Drops/min Adjustable
Electrode Material: Platinum, 5mm Diameter, 60 Degree Included Angle
Electrode Gap: 4mm (adjustable 3-6mm)
Test Solution: 0.1% NH4Cl Solution
Trip Current: 0.5A / 2s
Short Circuit Current: 1.0A
Control / Display: PC Software + 10-inch HMI
Test Stations: Single Station
Power Supply: AC 220V 50Hz
Machine Weight: 79kg
Machine Dimension: 800x500x1010mm
Highlight:

TTI-350 epoxy resin tracking index tester

,

temperature recording insulation material tester

,

plastic testing equipment for epoxy resin
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: WINTEST
Certification: ISO 9001:2015, CE
Model Number: TTI-350
Payment & Shipping Terms
Packaging Details: Export-grade wooden case with shock-proof foam padding and waterproof film
Delivery Time: 7 working days for stock, 20-30 days for production
Payment Terms: T/T, L/C, PayPal, Western Union
Supply Ability: 100 Sets per Month
Product Description

TTI-350 Tracking Index Tester (Comparative Tracking Index Tester) is a professional instrument designed to evaluate the tracking resistance of solid insulating materials under wet and contaminated conditions. It fully complies with IEC 60112, GB/T 4207 and is widely used in quality control laboratories, material R&D centers and third-party testing institutions.

Key Features

  • Ambient and specimen temperature logging
  • Built for epoxy resin evaluation
  • Multi-point data acquisition
  • Trend comparison across batches
  • Exportable CSV test records

Technical Specifications

ModelTTI-350
Test StandardIEC 60112, GB/T 4207
Test Voltage100V-600V AC adjustable
Drop Volume20 mm3 (+3/-0)
Drop Height30-40mm
Drop Rate1-60 drops/min adjustable
Electrode MaterialPlatinum, 5mm diameter, 60 degree included angle
Electrode Gap4mm (adjustable 3-6mm)
Test Solution0.1% NH4Cl solution
Trip Current0.5A / 2s
Short Circuit Current1.0A
Control / DisplayPC software + 10-inch HMI
Test StationsSingle station
Power SupplyAC 220V 50Hz
Machine Weight79kg
Machine Dimension800x500x1010mm

Typical Applications

Suitable for tracking index testing of epoxy resin, potting compounds, cast insulation. The instrument is essential for manufacturers exporting electrical and electronic products to markets requiring IEC 60112, GB/T 4207, ASTM D3638 or UL 746A compliance.

Warranty and Service

12-month warranty, lifetime technical support, free operation training video and installation guide. Calibration certificate and CE declaration available on request.
