BDV-50B Breakdown Voltage Tester 50kV AC DC IEC 60243-1 Plastic Film Sheet Insulation Testing

BDV-50B Dielectric Breakdown Voltage Tester is a professional high-voltage instrument used to determine the dielectric breakdown voltage and dielectric strength of solid insulating materials. It fully complies with IEC 60243-1, GB/T 1408.1 and is widely applied in material R&D, quality control and third-party testing laboratories.

Key Features

• High capacity film and sheet testing
• 50kV AC DC output capability
• Automatic breakdown detection
• Specimen thickness compensation
• Large touch screen control

Technical Specifications

Typical Applications

Suitable for dielectric breakdown testing of plastic films, sheets, high strength insulation. Essential for manufacturers exporting electrical and electronic products to markets requiring IEC 60243-1, GB/T 1408.1, ASTM D149 or IEC 60156 compliance.

Warranty and Service

12-month warranty, lifetime technical support, free operation training video and installation guide. Calibration certificate and CE declaration available on request.
