BDV-100C Dielectric Withstand Voltage Tester 100kV 10 Inch HMI for Transformer Insulation Test

BDV-100C Dielectric Breakdown Voltage Tester is a professional high-voltage instrument used to determine the dielectric breakdown voltage and dielectric strength of solid insulating materials. It fully complies with IEC 60243-1, GB/T 1408.1 and is widely applied in material R&D, quality control and third-party testing laboratories.

Key Features

• Transformer insulation test mode
• 100kV withstand capability
• 10 inch HMI plus PC software
• Oil immersed specimen support
• Long duration stability

Technical Specifications

Typical Applications

Suitable for dielectric breakdown testing of transformer insulation, bushing insulation, oil immersed parts. Essential for manufacturers exporting electrical and electronic products to markets requiring IEC 60243-1, GB/T 1408.1, ASTM D149 or IEC 60156 compliance.

Warranty and Service

12-month warranty, lifetime technical support, free operation training video and installation guide. Calibration certificate and CE declaration available on request.
