Products Description
Purpose:
This machine is specifically designed for the rubber industry and plastic product mixing experiments. It has the characteristics of light weight, small size, simple structure, easy operation, low power consumption, and convenient use and maintenance.
1. Equipment Application
This machine is specially designed for small-scale laboratory sampling, mixing and compounding of rubber and plastic materials. It features compact size, light weight, small floor space and low power consumption. With simple structure and easy operation, it is convenient for routine maintenance and inspection, ideal for micro-sample mixing in laboratories.
2. Main Technical Parameters
1. Roll Diameter: φ80mm (3 inches)
2. Working Length of Roll Surface: 160mm
3. Roll Gap Adjustment Range: 0.1–4mm
4. Roll Speed Ratio: 1:1.35
5. Rear Roll Linear Speed: 10.8m/min
6. Front Roll Linear Speed: 8.0m/min
7. Single Batch Feeding Capacity: 0.2–0.8kg
8. Electric Heating Power: 1.8KW
9. Temperature Control Range: Ambient temperature ~ 230℃
10. Roll Surface Treatment: Hard chrome plating on entire surface
11. Reducer Model: BWO150-23-2.2Kw
12. Overall Dimension (L × W × H): 720×580×950(mm)
13. Total Machine Weight: Approx. 320kg
Complete Machine Configuration Details
Roll Assembly
1. Structure Type: Hollow front & rear rolls for electric heating
2. Roll Material: Chilled Alloy Cast Iron
3. Working Surface Hardness: HRC 68～75
4. Supporting Parts: Wear-resistant Copper Bushings
5. Bearing Housing: FC30 cast iron, precision machined after stress relief tempering for stable rigidity and precision
6. Heating Type: Open-type electric heating
Base & Frame
1. Base: Thickened section steel, precision machined after stress relief tempering
2. Frame: Integrally cast FC30 grey cast iron with tempering treatment, anti-deformation and high precision
3.Roll Gap Adjustment Mechanism
Formed by bending integral stainless steel plate, corrosion-resistant and easy to clean
Transmission System
Main Drive Motor: 2.2KW, Rated Speed 1440rpm
Emergency Braking Device
1. Braking Type: Motor reverse connection braking
2. Operation Mode: Top pull rod emergency stop brake
Lubrication System
Grease lubrication for the whole machine; fill with grease regularly for maintenance
Electrical Control System
1. Control Cabinet: Small floor-standing cabinet with baking paint finish
2. Operation Unit: Integrated control circuit for temperature control and start-stop operation
3. Wiring Standard: All internal machine wiring is centralized to the terminal box on the machine. External cables between main machine and electrical cabinet shall be equipped by customers.
