ASTM D430 De Mattia Rubber Flex Cracking Fatigue Tester 6-Station Digital Counter ISO 132 for Tire and Dynamic Seal Testing

ASTM D430 De Mattia Rubber Flex Cracking Fatigue Tester 6-Station Digital Counter ISO 132 for Tire and Dynamic Seal Testing
Features Gallery Product Description Chat Now
Features
Specifications
Highlight:

ASTM D430 rubber flex tester

,

De Mattia fatigue tester 6-station

,

ISO 132 tire seal tester
Basic Infomation
Payment & Shipping Terms
Product Description

CF8590 De Mattia Flex Cracking & Fatigue Tester — Predict Rubber Failure Before It Happens

Rubber products that flex repeatedly in service—tire sidewalls, conveyor belts, engine mounts, seals—will eventually crack and fail. The question is: after how many cycles? The CF8590 De Mattia Flex Tester answers that question with ASTM D430 / ISO 132 precision. 6 stations · 300 cycles/min · Digital count to 999,999. Test your durability, or your customer will.

🔥 Why QC Managers Rely on the CF8590

✓ 6 Independent Stations — Test 6 samples or 6 different compounds simultaneously. 6x productivity vs single-station testers.
✓ 300 Cycles/Minute (5 Hz) — 18,000 flex cycles per hour. Simulate months of service in a single day. Fast compound screening.
✓ Digital Counter to 999,999 — Auto-stop at preset cycles or at first crack detection. Walk away and come back to finished tests.
✓ Built-in Inspection System — Integrated illumination and magnifier. Inspect crack initiation without removing samples from the machine.
✓ Servo Motor Drive — Stable, quiet, energy-efficient. Consistent 300 cpm regardless of sample stiffness. No belt slippage issues.
✓ 24/7 Duty Rating — Designed for continuous operation. Overtemperature and overload protected. Run weekend fatigue tests with confidence.

🎯 Costly Failures the CF8590 Catches Before Production

  • "The tire sidewall cracked after 20,000 km." → De Mattia flex testing at the compound development stage would have revealed insufficient crack resistance.
  • "Our conveyor belt developed cracks at the idler pulleys." → Flex fatigue testing simulates exactly this repeated bending. Qualify belt compounds properly.
  • "The engine mount rubber deteriorated prematurely." → Dynamic seals and mounts flex millions of times. The CF8590 subjects test specimens to realistic cyclic loading.
  • "We changed antioxidant supplier and now have field failures." → Comparative De Mattia testing of old vs new antioxidant formulations catches the difference.

📊 Test Specifications

StandardsASTM D430 Method B, ASTM D813, ISO 132, GB/T 13934
Test Stations6 independent (expandable to 12)
Frequency300 ± 10 cycles/min (5 Hz)
Stroke0 ~ 100mm adjustable via eccentric cam
Clamp Range0mm (closed) to 75mm (max open)
Counter0-999,999 per station, auto-stop
Crack AssessmentBuilt-in magnifier + graduated scale; USB camera option available

🏭 Products That MUST Pass De Mattia

Tire sidewall and tread compounds · Conveyor belt cover rubber · Engine mounts and vibration isolators · Rubber air springs · Dynamic shaft seals and diaphragms · Footwear soles · Rubber expansion joints · Marine fender rubber · Rubber bellows

📦 Complete Flex Testing System

CF8590 main unit (6-station) · Specimen cutting die (De Mattia type) · Sample grip sets (*6) · Magnifier inspection tool · Calibrated graduated scale · Touch screen controller · Operation manual (English) · Factory calibration certificate · 12-month warranty

💬 Common De Mattia Questions

Q: ASTM D430 vs ASTM D813 — which am I testing?
A: D430 Method B evaluates how many cycles until the FIRST crack appears (crack initiation). D813 evaluates how fast an existing cut grows (crack growth). The CF8590 does both—you choose the specimen type.

Q: How long does a typical test run?
A: It depends on your rubber. High-quality tire compounds can exceed 100,000 cycles before cracking. At 300 cpm, that's ~5.5 hours. Lower-grade compounds may crack in 5,000-30,000 cycles.

Q: Can specimens be inspected during testing?
A: Yes. Pause the machine, inspect with the built-in magnifier, record crack length, resume. The counter holds its value.

Q: Do you offer spare grip sets?
A: Yes, we keep grip sets, cutting dies, and all wear parts in stock for immediate shipment.
